It's fatal for digital sets if you make a mistake to select CAPACITOR inside
A leading CPU company makes
a dangerous bet that running through to a BLANK ZONE.
They ignore the theory of
digital.
However,
Non-polarized BLACK GATE breaks through all frequency bands easily
Which caps. do you choose
for your future digital sets beings as a wise consumer?
Time-bomb ticks in Pentium
motherboard: there has been a rumor so far, the accident becomes a reality
at last as its processor was up-grade for the type II of 200Mhz.
A magazine had above underlined
heading said a number of no-name brand electrolytic capacitor are used
on the boards and they caused PCs out of spec. It also mentioned
PCs would be all right if these caps were replaced with tantalums or O.S.caps.
Really?
It's too optimistic because
there's no capacitor can operate perfectly over the frequency 200MHz. Without
any improvement the mortal accident will occur which shakes the business
at the company to its foundation.
[1]In the BLANK ZONE, there's
no existence of capacitor can operate perfectly except BLACK GATE.
For the pulse transmission
of 200Mhz, its band is required at least 10 times or more than the value
of its pulse, hence there has to be 2GHz and above. Please look at
the "blank zone" on figure 1. If you use ordinary electrolytic capacitors
on sets for this zone ignoring its theory, the phase changes widely, the
pulse spacing isn't working properly and the CPU gets a heart attack, then
it will be greatly damaged (that's a common knowledge about pulse transmission!).
For this blank zone, no capacitors which could operate perfectly has been
invented except Black Gate.
[2]Reliability of dry-type
electrolytic capacitor is the worst in all kinds of caps.
We measured the distortion
(=reliability) about dry-type electrolytic caps: a tantalum, an O.S.cap.
and an aluminum solid by CLT-1 EX: a distortion measuring device having
the, highest sensitivity. The result is on Figure 2. All the dry-type ones
are over the standard level of -120dB by far, the worst in all kinds of
caps.
Moreover, they are weak
at the reverse pulse, but there has been no announcement that this point
can be improved.
Dry-type ones have to be
non-polarized originally, however, it has been impossible to produce it
yet. This is the another reason make their reliability the worst.
*Non-polarized
Black Gate is the champion of super high-speed digital transfer
As you are aware, Black
Gate is the greatest invention of the century that makes a new genre. The
internal speed of this becomes the Transcendence Electron Transfer: it's
nearly a light velocity. Moreover, the frequency range reaches even 10GHz.
Therefore the Black Gate satisfies the above heads not only [1], but also
[2] about reliability: the best capacitor in the world Please look at Figure
3: BG wins as a champion literally by an overwhelming margin over
any other electrolytic capacitors. This is the ideal one which for the
companies pursue digital has been waiting for eagerly. We expect very much
that motivated firm will start using the Black Gate.
Figure 1:Working frequency range of various
capacitors.
Figure 2: Reliability characteristics
at various capacitors
